Features
-
All coils are made form Boiler quality pipe tested to 1000 psi, type BS-3059-68/ Part I/CEW/St-33
-
Number of parallel paths provided on coil side to ensure low pressure drop across unit
-
Three pass design with a high efficiency having 1 radiant and 3 connective heat transfer areas thus eliminating need of a economizer
-
Double walled (two shell) construction provides for insulation as well as preheating of air thereby aiding combustion
-
High heat transfer area on coil
-
High furnace volume results in longer life of Thermal oil as degradation does not occur due to flame
-
Thermic Fluid Pump of KSB make with grafoil gland packing thereby achieving a lower connected load and minimum leakage problems
-
Panel components of reputed make like Siemens / telemechanique switches, contactors and relays
-
Flow rate of Thermic Fluid Pump gives a delta T across the system of maximum 30ºC. For lower delta T across system, it is available on request
-
Audio-visual alarm on panel and all pressure gauges also brought to panel avoids cumbersome procedures of fault-finding
-
All units are insulated with 50mm thick glass wool insulation and then covered with a 1.6mm thick M.S. sheet, thereby reducing radiation losses to a minimum
-
From Models D-600 onwards a folding shell design eliminates requirement of very high height requirement of Boiler House
-
Digital temperature controllers provide for + / – 1ºC accuracy on return and outlet temperature
-
Pressure switches for low and high pressure cut-off of Thermic Fluid Heater Pump
-
All brought out items are of reputed make and critical components of ISI standards thereby providing for long life of equipment
-
Oil preheater provided integral from Model D-400 onwards for easy switch over from light to heavy oil firing
-
Ammeter for pump current
-
Sufficient capacity of expansion cum dearator tank avoids flow problems
-
Bakelite moulded pressure gauges eliminates problems of seepage of dust and water.
-
Instantaneous back-up service with ready availability of spares
